Specifications：

Description	Unit	LTL60A
Paving width	mm	2800-6000
Paving thickness	mm	10-250
Paving speed	mm/min	3.07-9.16
Travelling speed	km/h	2.30-16.84
Theoretical productivity	t/h	300
Engine model & power	kw	QSB3.9-C110-30 Cummins,,81Kw*
Auger diamr	mm	350
Drive system		mechanical / hydraulic
Track shoe width	mm	wheel type
Machine weight	kg	12000
Screed extension model		hydraulic extension + mechanical joint
Screed heating model		Far infrared heating, automatic ignition
Screed vibration frequency	Hz	0-50
Auto. leveling unit		made in China
Hopper capacity	t	12
Fuel tank volume	t	200
Hydraulic tank volume	L	115
Centralized lubrication		made in China

Optional:

All information and specifications are correct at the time of print and are subject to change without prior notice.

Performance Characteristics:

With more than 30 years of innovation and development, wheel asphalt pavers reaches international advanced level based on technology transferred from abroad. The machine is used to pave asphalt for highway, urban road, plaza, and parking lots etc . It is the ideal machine for road construction.

The machine is equipped with hydraulical extension dual-layer screed and automatic leveling unit and can achieve good roads flatness and high density. The wearable parts are made from advanced wear resistance material to ensure durability.

●Advanced design & optimized configuration, operable for paving graded roads' surface.

●China made brand engine, powerful, low fuel consumption, low noise and high reliability and cold-starting.

●Independent feeding drive at LH & RH, removable and high-wearable auger blade for easy replacement.

●High-accuracy auto. Leveling sensors ensure mat’s surface flatness.

●Unique dual-layer and stepless-extension screed changes paving width easily, screed bottom plate uses international advanced wearable material.

●Centralized lubrication system, charging lubricating grease to all high temperature bearings for machine reliability.

●Fuel-electrodynamic cleaning system supplies convenient operation.

●Electrical system has advanced progress technology, all controlled elements and wirings are numbered as per circuit diagram for fast trouble shooting.

FAQ

Q1、How long will our price be valid?

Basically, our price remains stable through the year. We only adjust our price based on two situations:

1. The rate of USD:RMB varies significantly according to the international currency exchange rates.

2. The raw material cost increases much in short period.

Q2、What logistics ways we can work for shipment?

We can ship construction machinery by various transportation tools.

1. For 90% of our shipment, we will go by sea, to all main continents such as South America, Middle East, Africa, Oceania and Europe etc, either by container or RoRo/bulk shipmen.

2. For neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Uzbekistan etc., we can ship construction machinery by road or railway.

3. For light spare parts in urgent demand, we can ship it by international courier service, such as DHL, TNT, UPS, or Fedex.
